CS Series Features

*Low noise 12/16/20 channel Mic/Line-mixer.
*4/8/12 mono inputs with XLR-sockets, +48V Phantom-power and balanced line inputs.
*4 stereo inputs with balanced 1/4 jack sockets.
*Stereo inputs can also be operated mono.
*3-band EQ with semi-parametric mids for all mono inputs.
*4-band EQ for all stereo inputs.
*Peak-LED and switchable Low Cut per mono input.
*2 Aux-Send (pre/post) per channel for controlling external effectors and for monitoring.
*2 stereo Aux-Return with balanced 1/4 jack sockets.
*Built in DSP effect processor with 16 kinds of effects.
*16 presets DSP effect list please see Page 10 form C
*The mixer can be equipped an inner USB audio interface, by this part the mixer has a 16bit/48KHz A/D & D/A conversion function and an *USB data communication (communication rules with USB 1.1)function .Achieve the two-way exchange of PCM digital audio format between the computer and the mixer .(only for CS-U series).
*Separate Main Mix, Control Room and headphones outputs
*Stereo "TAPE IN" for recorder playback or CD playback or linking to sub-mixer.
*Record output.
*Precise 2x11 LED meter with peak hold.
*60-mm high-quality faders.
